Auger Machine
Auger Machine
We, SUNGWON Heavy Machinery, have been manufacturing and supplying
rock, soil drilling equipment and tools of DTH Hammers, Hammer Bits and
Auger Machines in Korea.
- Auger Machine
- Auger
SUNGWON Product
Auger
Auger Specification
Single
Augers
For Rod operation
Single Auger SPECIFICATION
| Specification |
|---|
| Motor |
| Rotation(rpm) |
| Rated Torque (kg-m) |
| Auger Center to Guide Center(mm) |
| Power Supply |
| Weight(kg) |
| SW-100P-S | SW-120P-SA | SW-120PW-SA1 | SW-120PW-SA2 | SW-150PW-SA1 | SW-150PW-SA2 | SW-200PW-SA |
|---|---|---|---|---|---|---|
| 75Kw × 4 / 8P × 1 | 90Kw × 4/8P × 1 | 45Kw × 4 / 6 / 8P × 2 | 45Kw × 4 / 6 / 8P × 2 | 55Kw × 4 / 8P × 2 | 55Kw × 4 / 8P × 2 | 75Kw × 4 / 8P × 2 |
| 34 / 17 | 10.6 / 5.2 | 26.3 / 17.3 / 13.2 | 19 / 12.5 / 9.5 | 18 / 9 | 6.1 / 3.08 | 4.18 / 2.1 |
| 2,105 / 4,211 | 8,105 / 16,523 | 3,300 / 4,900 / 6,640 | 4,535 / 6,873 / 9,051 | 5,960 / 11,930 | 17,430 / 34,788 | 34,258 / 68,190 |
| 744 | 850 | 1,300 | ||||
| AC 220V(380V) × 60Hz × 3P | ||||||
| 5,000 | 6,000 | 6,500 | 9,000 | 15,000 | ||
