40” DTH Hammer
SWH800L
| Hammer Model | |
|---|---|
| Bit Shank Type | SUNGWON |
| Atlas | |
| Sandvik | |
| Numa | |
| Bit Dia. | mm |
| Hammer Dia. | mm |
| Cylinder Bore | mm |
| Piston Stroke | mm |
| Piston Weight | Kgs |
| Length(Less Bit) | mm |
| Weight(Less Bit) | Kgs |
| Connection Type | |
| Air Consumption CFM(m3/min) |
100 psi 7.0 Kg/cm2 |
| 150 psi 10.5 Kg/cm2 | |
| 200 psi 14.0 Kg/cm2 | |
| 250 psi 17.6 Kg/cm2 | |
| 300 psi 21.0 Kg/cm2 | |
| 350 psi 24.1 Kg/cm2 | |
| SWH800L |
|---|
| SWH800 |
| 910~1500 |
| 800 |
| 600 |
| 150 |
| 732 |
| 2365 |
| 6600 |
| Hexagonal Joint |
| 3600(101.8) |
| 5330(151) |
| 6505(184) |
| 7358(208.2) |
| 8527(241.3) |
| 9853(278.8) |
