15” DTH Hammer
SWH350
| Hammer Model | |
|---|---|
| Bit Shank Type | SUNGWON |
| Atlas | |
| Sandvik | |
| Numa | |
| Bit Dia. | mm |
| Hammer Dia. | mm |
| Cylinder Bore | mm |
| Piston Stroke | mm |
| Piston Weight | Kgs |
| Length(Less Bit) | mm |
| Weight(Less Bit) | Kgs |
| Connection Type | |
| Air Consumption CFM(m3/min) |
100 psi 7.0 Kg/cm2 |
| 150 psi 10.5 Kg/cm2 | |
| 200 psi 14.0 Kg/cm2 | |
| 250 psi 17.6 Kg/cm2 | |
| 300 psi 21.0 Kg/cm2 | |
| 350 psi 24.1 Kg/cm2 | |
| SWH350 |
|---|
| SWH350 |
| 445~560 |
| 335 |
| 260 |
| 125 |
| 185 |
| 1900 |
| 1150 |
| Hexagonal Joint |
| 1015(28.7) |
| 1390(39.3) |
| 1610(45.5) |
| 2010(56.8) |
| 243(69.7) |
| 3075(87) |
